scherer8 (core router)

Monitor: http://monitor.berlin.freifunk.net/host.php?h=scherer8

This UBNT-ERX-SFP is set up as the core router in the Scherer8. It manages the DHCP client network for all freifunk nodes. It also meshes with the rooftop devices and all other nodes on the LAN.

IP Plan

Die Karte wird geladen …
Koordinaten:	52° 32' 53.36" N, 13° 22' 1.14" E
Karten:	OWM,OSM, GMaps
Knoten:	ado17-vh (OWM, Hopglass, Monitor), curly (OWM, Hopglass, Monitor), scherer8-abb (OWM, Hopglass, Monitor), scherer8 (OWM, Hopglass, Monitor)
über NN:	60
Adresse:	Schererstr. 8, 13347 Berlin-Wedding
Homepage:	http://hausprojektsch8.blogspot.de/
Ansprechpartner:	Perry
Community:	Berlin

The IP Addresses given to the Scherer8 are 10.230.229.0/24 for the Client Network, 10.230.226.192/26 for Meshing, and 2001:bf7:750:2e00::/56 to use without regard for anything since I have oh-so-very-many addresses.

DHCP Client Network managed by the core router.

Services

Weather Station

The first of hopefully many services was added to the Scherer8 on the 11th of December 2017. The weather station is built upon a Raspberry Pi. Currently the station measures the temperature, air quality, air pressure, relative humidity, wind speed, wind gust speed, wind direction, and precipitation.

The weather station is reachable on the Berlin Backbone at scherer8-wetter.olsrand it should also be possible to connect to the weather station from outside of the Backbone via 2001:bf7:750:2e0f::10.

Photos

Panoramas

best quality (166MB tiff) https://www.geroedel.de/cloud/index.php/s/yXxT9FR5zMQ1TOt/download

best quality (170MB tiff) https://www.geroedel.de/cloud/index.php/s/jQTnA7EERiAJlCv/download

best quality (183MB tiff) https://www.geroedel.de/cloud/index.php/s/gfLuVWDSuaMSIfI/download

best quality (175MB tiff) https://www.geroedel.de/cloud/index.php/s/YU7QjVSCiHOJmhX/download

Dachboden und Dach

My, what a beautiful rainbow!

Scherer8 Dach mit Mast und Solaranlage

Scherer8 Mast

Scherer8 Schrank

Scherer8 Wetterstation

Scherer8 Unter-dach Montage

Scherer8 New Years

Nachbarn

Standort	Blick zum Nachbarn	Blick von Nachbarn	Karte
Segenskirche
Beuthhochschule

Log

2014-02:16: First Freifunk Router installed
2016-03-07: Volker and Perry establish the first functioning freifunk link with Beuth.
2016-03-10: Perry changed the wireless connection to go over TU instead of Beuth, 10x performance enhancement.
2016-03-28: Perry installed the basta freifunk node. http://basta.blogsport.eu/
2016-04-12: Perry created the wiki page.
2016-04-16: Perry installed the scherer8-abb freifunk node.
2016-05-11: Perry updated the wiki page and added photos.
2016-05-21: Perry picked up MABB Hardware from the Lager
2016-05-25: Perry installed the TouchSwitch and PowerBeams from MABB
2016-07-06: Perry finally updated the Wiki
2016-07-13: Perry installed the NanoStation from MABB (SSID: Scherer8-Dach-Nordost)
2016-07-13: Perry updated Wiki
2016-08-31: Perry picked up MABB Hardware from the Lager
2016-09-01: Perry installed the NanoStation M2 from MABB (SSID: Scherer8-2Ghz-Dach-Suedost)
2016-09-03: Bastie and Perry establish the first functioning freifunk link with Hochstr. 13
2016-09-04: Perry uploaded device photos
2016-12-09: Perry upgraded to kathleen 0.2.0, added IPv6 support and there is now a dedicated dish on the segens kirche for the Scherer8
2016-12-12: Perry added IPv6 support to scherer8-abb and basta
2017-12-11: Peggy and Perry - Installation of the Scherer8 Wetterstation - [scherer8-wetter.olsr http://scherer8-wetter.olsr]
2018-01-02: Perry made updates to wiki
2018-03-10: Perry upgraded core router to Hedy on an ERX-SFP, installed scherer8-eg-o, scherer8-eg-s, and scherer8-eg-nw
2018-03-28: Perry updates to wiki
2024-01-31: Perry installed new mast, fresh install of firmware on the ER-X-SFP
2024-02-04: Perry reinstallation of the weather station
